Portable 30 Ton Wireless Truck Scales
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | Alloy Steel | Color: | Black,orange |
|---|---|---|---|
| Protection Class: | IP66 | Cable Spec: | 4-wire Shield Cable |
| Max. Load For Single Point: | 10t | Rated Capacity: | 15t |
| High Light: | Truck Axle Scales,Portable Axle Weigher |
||
Portable wheel electronic mobile 30 Ton truck scale rental,wireless truck scale
Description:
Aluminum-alloy; Ultra thin weigh pad design; Easily mounted / unmounted slope; Hermetically sealed, suits different environment;Works both dynamically and statically;Can be used to measure axle weight and whole vehicle weight when two or four weigh-pad connected together.
Specifications:
| Output Sensitivity ( m V/V): | 0.9±0.2 |
| Combined Error (%ld): | 0.5 |
| Non-Linearity (%ld): | 0.5 |
| Repeatability (%ld): | 0.1 |
| Creep (%FS/30min): | 0.1 |
| Input Resistance (Ω): | 3120±40 |
| Ouput Resistance (Ω): | 2800±10 |
| Insulation Resistance(MΩ): | ≥5000(100VDC) |
| Zero Balance (%FS): | 4～10%FS |
| Temperature Effect On Sensitivity (%FS/10℃ ): | 0.1 |
| Temperature Effect On Zero (%FS/10℃): | 0.1 |
| Temperature, Compensated (℃): | -10～+50 |
| Temperature, Operating (℃): | -40～+80 |
| Excitation, Recommended (V): | 9～15DC |
| Excitation, Max.(V): | 20DC |
| Safe Overload (%FS): | 120 |
| Ultimate Overload (%FS): | 150 |
| Protection Class: | IP66 |
| Cable Spec.: | 4-wire shield cable |
| Max. Load For Single Point (t): | 10t |
| Rated Capacity (t): | 15t |
| Connections: Red Input(+) Black Input(-) Green Output(+) White Output(-) | |
Applications:
1. Load control and weighing for the vehicles.
2. Measuring the weight and barycenter of aeroplane.
3. Measuring weight for special purpose.
Competitive Advantage:
1. your inquiry and e-mai will be replied within 12 hours.
2. If you need to develop product with your own specification, we have professional engineers to work it out.
3. Never leave customer alone, solve problems with customer together.
4. Customer first, quality first, service first!
